Single Stage L.P.G Regulator
General Details
A brass single stage regulator with neoprene diaphragm for general purpose welding & cutting applications. The regulators are specifically designed to control flow of LPG , offering consistent , smooth operation featuring a well designed knob for pressure adjustments .
Features
- Body & bonnet made from high strength brass .
- Chrome plated bonnet to resist corrosion .
- Can be connected directly to cylinder valve .
- Single stage construction .
- Compact design .
- Conforms to IS:6901
- PVC Molded adjustment knobs for smooth flow settings.
Specifications
| MODEL | ITEM CODE | MAX. INLET PRESSURE (bar) | MAX. OUTLET PRESSURE (bar) | FOW RATE M3/hr (min.) | INLET CONNECTION | OUTLET CONNECTION |
| 11LP | 1010001103 | 18 | 1.3 | 1.2 | To fit directly on industrial lpg cylinder valve | 3/8” BSP(LH) |
| 10LP | 1010001104 | 18 | 1.3 | 1.2 | To fit directly on industrial lpg cylinder valve | 3/8” BSP(LH) |
| 22LP | 1010001109 | 18 | 1.3 | 1.2 | 7/8” BSP(LH) , use adopter , supplied extra to fit on cylinder valve | 3/8” BSP(LH) |
